Model 10 Specifications

50 ohm input impedance mode

Probe Wire Length

0.120 inch

0.030 inch

Frequency Response

DC to 3.5 GHz

DC to 7 GHz

Insertion loss

3dB

3dB

Retum Loss

Greater than 10dB

Greater than 10dB

Attenuation

1:1

1:1

250 ohm input impedance mode

Frequency Response

DC-10GHz(-3dB)

Attenuation

5:1

500 ohm input impedance mode

Frequency Response

DC-11GHz(-3dB)

Attenuation

10:1

5K ohm input impedance mode

Frequency Response

DC-5GHz(-3dB)

Attenuation

100:1
